Ice glazing machine is mainly used to glaze fish fillet, fish, prawn, shrimp or other seafood.
Ice glazing machine is made of food grade stainless steel. It can fully meet food hygiene standard.
The belt speed can be adjusted by variable speed controller installed on control panel.
We use immersing glazing together with spraying glazing to guarantee the glazing effect.
Work together with spiral IQF freezer or tunnel IQF freezer.
NO. | ITEM | CONTENT |
1 | Equipment Type | Ice Glazing Machine |
2 | Output Capacity | 800~1200kg/h (according to materials) |
3 | Installed Power | 1.12KW |
4 | Overall Dimension | 3000mm*900mm*1100mm L*W*H |
5 | Reducer Power | 0.37KW |
6 | Reducer Speed ratio | 20:1 |
7 | Pump Power | 0.75KW |
8 | Pump Flow | 3 tons per hour |
9 | Water Consumption | 0.3 tons per hour |
10 | Belt Width | 523mm |
* Customized design equipment according to floor plan
* Equipment technical consultation service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
